SPACE

SPACE 500 and SPACE 700 are vertical double flow heat recovery ventilation systems designed for efficient air renewal. With 500 m³/h airflow, 95% thermal efficiency, automatic bypass and M5, G4 and F7 filtration, the SPACE series combines high ventilation performance with A+ energy classification.

Features

Technical Characteristic SPACE 500 SPACE 700
Power Max. 170 W 170 W
Power Supply 230 V 230 V
Air Flow 500 m³/h 700 m³/h
Noise 26 dB 36 dB
Input / Output Filter M5, G4 and F7 M5, G4 and F7
Automatic By Pass 100% 100%
Thermal Efficiency 95% 95%
Sensors Carbon Dioxide Carbon Dioxide
Control Digital Panel SI Digital Panel SI
Installation Vertical Vertical
Energy Classification A+ A+
Weight 170 kg 170 kg

SPACE is a double flow heat recovery ventilation system designed to provide continuous air renewal while recovering heat from the extracted air. The SPACE range features a vertical installation configuration, automatic 100% bypass and high thermal efficiency of up to 95%. The system uses M5, G4 and F7 filters and includes a digital panel and carbon dioxide sensing. With an airflow of up to 500 m³/h and A+ energy classification, SPACE provides an efficient ventilation solution for applications requiring controlled indoor air circulation.

Variations

SPACE 500

  • Power Max.: 170 W
  • Power Supply: 230 V
  • Air Flow: 500 m³/h
  • Noise: 26 dB
  • Input / Output Filter: M5, G4 and F7
  • ‍

    SPACE 700

  • Power Max.: 170 W
  • Power Supply: 230 V
  • Air Flow: 700 m³/h
  • Noise: 36 dB
  • Input / Output Filter: M5, G4 and F7
