DOMINION

DOMINION 560 and DOMINION 700 are vertical double flow heat recovery ventilation systems with up to 560 m³/h airflow, 100% automatic bypass and digital control. The series combines G4 filtration with temperature and humidity sensing and A+ energy classification.

Features

Technical Characteristic DOMINION 560 DOMINION 700
Power Max. 240 W 240 W
Power Supply 230 V 230 V
Air Flow 560 m³/h 700 m³/h
Noise 48 dB 48 dB
Input / Output Filter G4 G4
Automatic By Pass 100% 100%
Thermal Efficiency 90% 88%
Sensors Temperature and Humidity Temperature and Humidity
Control Digital Panel Digital Panel
Installation Vertical Vertical
Energy Classification A+ A+
Weight 70 kg 70 kg

The DOMINION series is a vertical double flow heat recovery ventilation solution designed for efficient air circulation and heat recovery. DOMINION models provide airflow of up to 560 m³/h, operate at 230 V and use G4 filtration. The systems include 100% automatic bypass, digital control and temperature and humidity sensors. With thermal efficiency values of up to 90% and A+ energy classification, DOMINION provides a high-performance ventilation solution in a compact vertical configuration

Variations

DOMINION 560

  • Power Max.: 240 W
  • Power Supply: 230 V
  • Air Flow: 560 m³/h
  • Noise: 48 dB
  • Input / Output Filter: G4
  • DOMINION 700

  • Power Max.: 240 W
  • Power Supply: 230 V
  • Air Flow: 700 m³/h
  • Noise: 48 dB
  • Input / Output Filter: G4
